Technical Specifications
Item NO.：3WWDZ-50A
Product Name：B100 Agriculture Drone
Flight Control System
FC model：AG6
Included modules:Main controller, front HUB board,
rear HUB board, data chain antenna, distribution board,
GPS, navigation lights, RTK, fuse module, spraying
HUB, weight hub, weight sensor
Positioning
mode：GPS（BDS、GPS、GLONASS、GALILEO
）/RTK
Suitable voltage：12V
Rated power：100W
Working temperature：0—60℃
Dimension of Main Controller: 200.5*120.5*55.5mm
Weight of Main Controller: 574g
size
Rotor diameter：1430mm
Dimensions (working status)：1725*1755*1075mm
power System
Power Model: HW-X13-18S
Stator: 138*25mm
KV Value: 45rpm/V
Maximum Tension (69V): 57kg/axle
Rated Power: 3500W
Maximum Operating Voltage: 81V
Blade Dimension/Screw Pitch: 56*20 inch
Empty weight: 55kg
Rated Take-off Weight: 88.4kg
Maximum Take-off Weight: 107kg
Hover Precision Enabled Network RTK: Horizontal
±10cm, Vertical ±10cm
Hover Precision Disabled Network RTK: Horizontal
±60cm, Vertical ±60cm
RTK/GNSS Frequency Band Used: BDS B1/B2/B3;
GPS L1 /L2/L5; GLONASS G1/G2/G3; GALILEO
E1/E6/E5a/E5b; QZSS L1/L2;
Maximum Power Consumption: 16000W
Fully-loaded Hover Time: 7min
Maximum Flight Speed: 12m/s
Maximum Tolerable Wind Speed: 8m/s
Operation Tank
Rated Capacity: 50L
Material of Pesticide Tank: HDPE
Nozzles
Nozzle Type: Centrifugal
Quantity: 2
Length of Spray Rod: 1620mm
Model: CN12
Liquid Pump Type: Diaphragm Pump
Flow Rate of Liquid Pump: 12L/min
Quantity of Liquid Pump: 1
Spraying Width: 6-8m (1.5-3m away from the
crops)
Flowmeter
Measuring Range: 1-30L/Min (single channel)
Flow Measuring Error: ±2％
ZAB1830 Secondary Lithium Ion
Battery Pack
Battery model：ZAB1830
Battery voltage：68.4V
Nominal capacity：30000mAH
Charging voltage：78.3V（maximum）
Recharging current：Max≤120A
Discharge voltage：59.4V—78.3V
Working temperature (discharge)：0℃－60℃
Operating temperature
(charging）：5℃－65℃
Storage temperature: -10°C-30°C
Weight: ≈13.5KG
Dimensions (length, width and height):
175mm *275mm*309mm
