Remote Control H12 PRO
Built-in Battery: 4.2 Lithium Battery
Battery Capacity: 20000mAh
Operating Environment Temperature: -10°C
to 55°C
Storage Temperature: -25℃ to 70℃
Frequency Band: 2.400-2.483GHz
RF Power: 17.5dBm
Transmitting Power: 2.4G:16.0±1.5dBm&<
-15dB@11b 11Mbps;14.0±1.5dBm&<
-25dB@11g
54Mbps13.0±1.5dBm&<-28dB@11n-HT20-
2.4G-MCS7;13.0±1.5dBm&<-28dB@11n-H
T40-2.4G-MCS7
Transmission Distance: Open space air-to-air:
6-10KM open space ground: 1.2-1.5KM
indoor 3-4 walls: 30m
Charger model：ZACC090-01
Recharging current：
fast charging 90A；slow charging 30A
Charging power：
fast charge 8000；slow charge 2500W
Charging time：
fast charging 13min（20%—95%）
Slow charging time:
slow charging 45min（30%—100）
Protection function:
short circuit, reverse connection, over
temperature protection
Weight：≈17.5Kg
Size：400*260*340mm
Input voltage：100-380V ac
Output voltage：78.3V/104.4V
Output current：
100—176Vac：78.3V Max. 45.0A/ 104.4V
Max.40.0A
176—380Vac：78.3V Max.90.0A / 104.4V
Max.90.0A
Transmitting Frequency: 24.00 -24.25 GHz
Transmitting Power: 12dBm
Antenna Gain: 14.8 dB
Ranging Range: 0.5-25m
Precision: ±0.1m
Obstacle
Working Frequency: 60GHz
Transmitting Power: 10dBm
Antenna Gain: 14.5dB
Detection Scope:
>15m, detecting 1cm wires
>20m, detecting 15cm power line poles
>20m, detecting 10cm tree trunks
Field of View (FOV): Vertical ± 9°
Horizontal 80°
Safety Distance: 5m
(Distance to obstacle after identifying and
hovering)
Obstacle Avoidance Direction: Front and Rear
