Note
Optionally, the tip of the pressure gauge’s rubber vent seal
may be clipped with a knife or scissors prior to installation.
This will eliminate the small drift in pressure readings that
occurs with sealed gauges as the 6D unit warms with
continuous, extended use. Venting the gauge may be
advantageous if pressure settings must be precisely
monitored or adjusted during extended run times. Venting
should not be necessary for most users.
The 6D unit must remain upright if the vent seal is
trimmed, or the glycerin liquid filling the gauge will leak
out
Number
1 Pressure Gauge, 0-30 psi 5300169
1 Right-Angle quick-disconnect
fitting
5100913
3 Countersunk gauge lock
washer
3200186
3 Flat head gauge screw 3300484
Table 2 Calibrated Pressure Gauge Replacement Kit 9300250
