APPENDIX A
Specifications
Physical Characteristics
Dimension (L x W x H) 14.8 in x 10.1 in x 10.9 in
37.4 cm x 25.7 cm x 27.6 cm
Weight 34 lb (15.4 kg) empty of oil, including
sanitary flange
36 lb (16.4 kg) full of liquid aerosol
reagent
Liquid Aerosol Reagent
Capacity
32 fluid ounces (1 quart) (945mL)
Maximum reservoir capacity
8.9 fluid ounces (264mL)
Between MIN and MAX fill
Laskin Nozzle Output
Pressure
Under 10 PSI to over 20 PSI
Operational Requirements
Power 115 VAC, 60 Hz, 5.5 Amps (for Part
Number 9300237)
230 VAC, 50 Hz, 2.8 Amps (for Part
Number 9300238)
Aerosol Reagent PAO-4, DOS, Ondina EL, DOP, Mineral
Oil, Paraffin, or Corn Oil liquid aerosol
reagent.
Duty Cycle Intermittent on/off; or
Less than 1 hour on and
More than 15 minutes off
