Air Techniques ScanX Touch - EMC Immunity Measurements

Page 15Air Techniques, Inc.
Electromagnetic compatibility (EMC) Interference
immunity measurements supply input
Immunity to interference, rapid transient bursts
AC voltage grid
IEC 61000-4-4:2012
±2k V
100 kHz repetition frequency
Compliant
Immunity to interference, surges
IEC 61000-4-5:2005
±0.5 kV,±1kV
Compliant
Immunity to interference, line-conducted d isturbances
induced by high-frequency fields – AC voltage grid
IEC 61000-4-6:2013
3V
0.15-80 MHz
6V
ISM frequency bands
0.15-80 MHz
80% AM at 1kHz
Compliant
Immunity to interference due to voltage dips, short
interruptions and voltage variations
IEC 61000-4-11:2004
Compliant
Electromagnetic compatibility (EMC) Interference
immunity measurements SIP/SOP
Immunity to interference, discharge of static electricity
IEC 61000-4-2:2008
±8 kV contact
±2 kV, ±4 kV, ±8 kV, ±15 kV air
Compliant
Immunity to interference, rapid transient bursts – I/O, SIP/
SOP ports
IEC 61000-4-4:2012
± 2 kV
100 kHz repetition frequency
Compliant
Immunity to interference, line-conducted disturbances
induced by high-frequency fields – SIP/SOP ports
EC 61000-4-6:2013
3V
0.15 - 80 MHz
6V
ISM frequency bands
0.15 - 80 MHz
80% AM at 1 kHz
Compliant
