Airsight XX59A - 1.5 Hardware Installation

6
1.4 PC System Requirements
System configuration requirements:
CPU: 2.06 GHZ or above.
Memory: 256M or above.
Network Card: 10M or above.
Display Card: 64M or above memory.
Recommended Operating system: Windows XP, Windows Vista, Windows 7.
1.5 Hardware Installation
Follow the steps below to set up your camera hardware.
1.
Install the Wi-Fi antenna
.
2.
Plug the power adaptor into the camera and into an AC outle
t.
3.
Plug the network cable into the camera and router/switch.
4.
It takes approx 30 seconds to boot up the camera, then you will find the IP address from Sear
ch
IP
Cam Tool (Figure 1.
5).
5.
When the power is on and the network cable is connected, the green LED on the rear panel will
stay on
.
The yellow LED will keep flashing, and the Indicator LED on the front of the camera will flash.
(The indicator LED can be controlled by software).
