7. SPECIFICATIONS
Image Sensor
Image Sensor 1/4" Color CMOS Sensor
Display Resolution 1280 x 720 Pixels (1000K Pixels, i.e. 1 Megapixel)
Lens f: 4.2 mm, F:2.0 (IR Lens)
Mini. Illumination 0.5 Lux
Viewing Angle 60 Degree
Audio
Input Built-in Microphone/1 channel audio input
Output 1 channel audio output
Audio Compression ADPCM
Video
Image Compression H.264, MJPEG
Image Frame Rate 30fps (VGA),30fps (QVGA)
Resolution 1280 x 720 (VGA), 640 x 368 (VGA), 320 x 208 (QVGA)
Flip Mirror Images Vertical / Horizontal
Light Frequency 50Hz, 60Hz
Video Parameters Brightness, Saturation, Contrast, Hue
Communication
Ethernet Interface Build in 10/100Mbps,Auto MDI/MDIX , RJ-45
Supported Protocol
TCP/IP HTTP DNS DHCP PPPoE SMTP FTP SSL TFTP NTP
ARP/RARP NFS RTSP RTP RTCP
Compress rate level
128Kbps～4Mbps
Wireless Standard IEEE 802.11b/g/n
Data Rate
802.11b: 11Mbps (max.), 802.11g: 54Mbps (max.), 802.11n: 150Mbps (max.)
Wireless Security WEP & WPA WPA2 Encryption
Physical
Pan/Tilt Angle Horizontal: 270° & Vertical: 120°
Infrared Light 10 IR LEDs, Night visibility up to 15 meters
Alarm Input 1 Channel on/off Input
Alarm Output 1 Channel relay Output
Power
Power Supply DC 5V/2.0A (EU,US,AU adapter or other types optional)
Power Consumption 7 Watts (Max.)
Environment
Operate Temper. 0° ~ 55°C (14°F ~ 131°F)
Operating Humidity 20% ~ 85% non-condensing
Storage Temper. -10°C ~ 60° (14°F ~ 140°F)
Storage Humidity 0% ~ 90% non-condensing
PC System
Requirements
CPU 2.0GHZ or above (suggested 3.0GHz)
Memory Size 256MB or above (suggested 1.0GHz)
Display Card 64M or above
Supported OS Microsoft Windows 2000/XP/Vista/7
Browser IE6.0/7.0/8.0/Firefox/Safari/Google chrome or other standard browsers
Certification
CE, FCC, RoHS
