Airspan ProST - System Overview

System Overview
9
ProST Frequency Ranges
The table below lists the frequency range of ProST models currently available. This table will grow
as more models become available.
Frequency Band Channel Bandwidth
1.4265 – 1.524 in GHz TDD mode 1.75 MHz
3.5 MHz
5 MHz
3.3 – 3.5 GHz in TDD mode 1.75 MHz
2.75 MHz
3.5 MHz
5 MHz
3.4 – 3.6 GHz in FDD mode 1.75 MHz
3.5 MHz
3.6 – 3.8 GHz in TDD mode 1.75 MHz
3.5 MHz
5 MHz
4.9 – 5.0 GHz in TDD mode 2.5 MHz
5 MHz
10 MHz
5.15 – 5.35 GHz in TDD mode 2.5 MHz
5 MHz
10 MHz
5.47 – 5.725 GHz in TDD mode 2.5 MHz
5 MHz
10 MHz
5.725 – 5.875 GHz in TDD mode 2.5 MHz
5 MHz
10 MHz
5.850 – 5.950 GHz in TDD mode 2.5 MHz
5 MHz
10 MHz
Main Features
The ProST provides the following main features:
Full Outdoor Non-LOS Deployment: 256 OFDM
Based on the latest wireless technology WiMAX IEEE 802.16 standard
Integrated antenna gain of 15 dBi or 16 dBi (latest version)
Indoor Ethernet adapter (SDA-1 Type II):
