Airspan ProST - Prost-2 Frequency Ranges

605-0000-706 ProST Installation User Guide-Rev I
10
o providing power and interface termination
o up to 100-m Category 5 cable between ProST and SDA-1
Indoor:
o SDA-4S Type II: small low cost IDU with built in LAN switch
o SDA-4SDC Type II: small low cost DC IDU with built in LAN Switch
o SDA-WiFi: enabling WiFi capability to the ProST CPE (optional)
o SDA-MSG (Multi-Service Gateway): enabling VoIP capability to the ProST CPE
(optional)
High throughput providing fast access at burst data rates up to 37 Mbps over-the-air (gross
rate) over up to a 10 MHz channel
Option of LAN switch with indoor adapter
Up to 4 ports with VLAN port switching
Supports multiple UL bursts per SS frame
Signal information can be obtained via Web Management Performance tool
Integral WiFi and LAN switch
Optional VoIP module -- available SDA-MSG, an extension module allowing you to add VoIP
functionality to your ProST unit(s).
Optional WiFi module -- available SDA-WiFi, an extension module allowing you to add WiFi
functionality to your ProST unit(s).
Note: Contact your Airspan representative for more information on the SDA-MSG VoIP
extension module or the SDA-WiFi extension module.
ProST-2 Frequency Ranges
The table below lists the frequency range of ProST-2, TDD/FDD Multimode models currently
available. This table will grow as more models become available.
Frequency Band Channel Bandwidth
3.4 – 3.6 GHz in TDD/FDD 50/100 mode 1.75 MHz
2.75 MHz
3.5 MHz
5 MHz
7 MHz
10 MHz
3.6 – 3.8 GHz in TDD/FDD 50/100 mode 1.75 MHz
2.75 MHz
3.5 MHz
5 MHz
7 MHz
10 MHz
Main Features
The ProST-2 provides the following main features:
