605-0000-706 ProST Installation User Guide-Rev I
18
Note: The SDA-4S Type II and the SDA-4SDC are physically (externally) the same other
than the power socket.
SDA-4S Type II and SDA-4S/VL Type II (Optional)
The SDA-4S Type II and SDA-4S/VL Type II indoor units (hereafter referred to as SDA-4S) are two
optional integrated LAN switches that offer an alternative to the SDA-1 Type II unit. These two units
have identical physical dimensions and design, as displayed in the figure below.
This subsection provides the following SDA-4S physical descriptions:
Dimensions
Ports
LEDs
Physical Dimensions
The SDA-4S Type II and SDA-4S/VL Type II physical dimensions are described in the table
below:
Parameter Value
Dimensions (L x W x H) 200 x 150 x 40 mm (7.87 x 5.9 x 1.57
inches)
Weight 0.577 kg
