605-0000-706 ProST Installation User Guide-Rev I
30
b. Adjust the horizontal position of the ProST by rotating it about the pole, and then
tightening the nuts of the U-bolts.
Note: A thread-locking compound must be used to prevent the bolts from working loose.
ProST positioning is obtained in two planes by adjustment of the mounting bracket assembly as
shown below:
Note: It is important to provide strain relief and drip loop for Cat-5 cables. Create a drip
loop and strain relief using cable tie, to tie cable to pole, as displayed in the figure below.
