Network Cabling
39
Cable: Straight-through (e.g. when connecting to PC) or crossover (i.e. when connecting to
a hub) CAT 5 Ethernet cable
Connectors: 8-pin RJ-45 at both ends
Connector pinouts:
o Straight-through cable (e.g. connecting to a PC)
Pin Function 8-Pin RJ-45
1 Tx+
2 Tx-
3 Rx+
6 Rx-
o Crossover cable (e.g. connecting to a hub)
Pin Function Pin Function 8-Pin RJ-45
1 Rx+ 3 Tx+
2 Rx- 6 Tx-
3 Tx+ 1 Rx+
6 Tx- 2 Rx-
