Akai MPD32 User Manual

17
MINIMUM RANGE FIELD
MAXIMUM RANGE FIELD
MIDI PORT/CHANNEL FIELD
AFTERTOUCH PARAMETERS
For some applications, you might wish to use the faders or knobs as Aftertouch controllers. In this scenario,
the knob or fader will transmit Aftertouch information which could be used to control, say, vibrato or tremolo.
The following list of parameters can be accessed if “Aftertouch” is selected as the event type for the knob or
fader.
MIDI CHANNEL FIELD
This field sets the MIDI Port and Channel which the knob or fader will use to
transmit messages. You can assign knobs and faders to one of two MIDI Ports,
A or B, and to one of 16 MIDI Channels on each port (i.e. A14). You can also
assign a knob or fader to use the MIDI Common Channel.
1. Press [<] to select MIDI Port/Channel field.
2. While in MIDI Port/Channel field, use [VALUE] dial to select desired MIDI
Port and Channel.
3. Press [>] to select the next field.
Note: When not used via USB, only knobs and faders assigned to port A
will be transmitted via the 5-pin MIDI port on the back of the MPD32.
MINIMUM RANGE FIELD
This field is used to specify the minimum value that the knob or fader can
transmit.
1. Use [<] or [>] buttons to select Minimum Range field.
2. While in Minimum Range field, use [VALUE] dial to select desired minimum
aftertouch value.
3. Use the [>] button to select the next field.
MAXIMUM RANGE FIELD
This field is used to specify the maximum value that the knob or fader can
transmit.
1. Use the [<] or [>] buttons to select Maximum Range field.
2. While in Maximum Range field, use [VALUE] dial to select desired maximum
value.
When finished editing, press [ENTER] to save or [<] to cancel the changes.

Akai MPD32 Specifications

General

Mixer section	-
Product color	Black
Drum pads backlight	Yes
Number of drum pads	16
Display type	LCD
USB connector type	USB Type-B
Power supply type	USB

Weight and Dimensions

Depth	384 mm
Width	308 mm
Height	64 mm
