Akai MPD32 User Manual

18
MIDI PORT/CHANNEL FIELD
INCREMENT/DECREMENT PARAMETERS (knobs only)
The endless knobs on the MPD32 may also be used as an increment/decrement NRPN function. This allows
you to use the knob to increment and decrement through parameters as opposed to sending an absolute
value. Please note that the implementation of NRPN functions depends strictly on the software with which you
will be using the MP49. Consult your software’s documentation to find out how NRPN functions are
supported.
MIDI CHANNEL FIELD
This field sets the MIDI Port and Channel which the knob will use to transmit
messages. You can assign the knobs to one of two MIDI Ports, A or B, and to
one of 16 MIDI Channels on each port (i.e. A14). You can also assign knobs to
use the MIDI Common Channel.
1. Press [<] to select MIDI Port/Channel field.
2. While in MIDI Port/Channel field, use [VALUE] dial to select desired MIDI
Port and Channel.
3. Press [>] to select the next field.
Note: When not used via USB, only knobs assigned to port A will be
transmitted via the 5-pin MIDI port on the back of the MPD32.
BANK M FIELD
Bank M describes the Most Significant Bit (MSB) of information.
1. Use [<] or [>] buttons to select Bank M field.
2. While in Bank M field, use [VALUE] dial to select desired value.
3. Use the [>] button to select the next field.
BANK L FIELD
Bank L describes the Least Significant Bit (MSB) of information.
1. Use the [<] or [>] buttons to select Bank L field.
2. While in Bank L field, use [VALUE] dial to select desired value.
When finished editing, press [ENTER] to save or [<] to cancel the changes.
BANK M FIELD
BANK L FIELD

Akai MPD32 Specifications

General

Mixer section	-
Product color	Black
Drum pads backlight	Yes
Number of drum pads	16
Display type	LCD
USB connector type	USB Type-B
Power supply type	USB

Weight and Dimensions

Depth	384 mm
Width	308 mm
Height	64 mm
