Akai MPD32 User Manual

30
PRESS ENTER TO TRANFER
SAVE SETUP – Page 9
SAVE SETUP allows you to save any changes you may have made to
the global parameters.
1. While in Global Mode, press [>] to scroll to Globals (page 9). You
will see “Save Setup” displayed on the screen.
2. Press [ENTER] to save all the global settings on the MPD32.
SYSEX TX – Page 10
SYSEX TX allows you to transfer Preset data from the MPD32 via
SysEx. This data includes Controller Numbers, MIDI Channels and
various other parameters.
1. While in Global Mode, press [>] to scroll to SysEx Tx (page 10).
2. Turn the [VALUE] dial to select which Preset’s information you
would like to transfer.
3. Press [ENTER] to save all the global settings on the MPD32.
VERSION – Page 11
VERSION allows you to see what version of the operating system and
firmware is currently loaded onto the MPD32.
While in Global Mode, press [>] to scroll to Ver (page 11) for version
information.
PRESS ENTER TO SAVE
CHOOSE PRESET
SysEx transfers to the MPD32
You can also load preset data into the MPD32 from an external
source by “playing” a SysEx file into the MPD32. This can be done
with a variety of SysEx applications, many of which are widely and
freely available over the Internet.
1. Make sure that the device is connected to the MPD32 either
via the USB or the MIDI IN port.
2. Make sure that you are in Preset Mode.
3. “Play” the SysEx file on your external device or computer.
Please note that when transferring SysEx information into the
MPD32, the data will override the data of the original Preset which
was sent to your SysEx editor. For example, if you transfer Preset
5 to your SysEx editor and then send it back to the MPD32, the
data will overwrite Preset 5.

Akai MPD32 Specifications

General

Mixer section	-
Product color	Black
Drum pads backlight	Yes
Number of drum pads	16
Display type	LCD
USB connector type	USB Type-B
Power supply type	USB

Weight and Dimensions

Depth	384 mm
Width	308 mm
Height	64 mm
