Page #46 background imageLoading...
Page #46 background image
Page 46 of 80
Install the Small Capacitors
Now we’ll install the following small capacitors. If you have a lead-bending jig, use the
0.4” spacing:
Designation Value Description Done
C6
100p
COG, marked 101K
5
C7
100p
COG
C8
100p
COG
C9
100p
COG
C10
100p
COG
C11
100p
COG
Install the Diodes
If you’re using a lead-bending jig:
Use a 0.45” span for the 1N4004 diodes
Use a 0.40” span for the 1N4148 diodes
Install the diodes correctly. Make sure to match the banded end of the diode
to the
banded end of the diode’s silk
-
screen.
Designation Value Description Done
D1
1N4004
1 Amp 400 PIV diode
D2
1N4004
1 Amp 400 PIV diode
D3
1N4004
1 Amp 400 PIV diode
D4
1N4004
1 Amp 400 PIV diode
D5
1N4004
1 Amp 400 PIV diode
D6
1N4004
1 Amp
400 PIV diode
D7
1N4004
1 Amp 400 PIV diode
D8
1N4004
1 Amp 400 PIV diode
D9
1N4004
1 Amp 400 PIV diode
D10
1N4004
1 Amp 400 PIV diode
D11
1N4148
75 V switching diode
D12
1N4148
75 V switching diode
Install the Bypass Capacitors
The bypass capacitors are pre-formed to the correct span. Drop each one in, and bend the
leads to around a 45 degree angle to hold the capacitors. Solder, then clip the leads in the
normal fashion.
5
There’s also a line that says K1G, but you need even more magnification to see that!
