Install the Tall Capacitors
Designation Value Description Done

C2
2.2 nF
Film cap, 63 volt
, marked 2n2K63
C8
2.2 nF
Film cap, 63 volt, marked 2n2K63
C1 0.1 µF
Film cap,
100
volt
, marked

1J100
C7 0.1 µF
Film cap, 100
volt
,
marked

1J100
C4
1 µF
Film cap
, 63 volt, marked 1J63
C10
1 µF
Film cap, 63 volt, marked 1J63
Install the Electrolytic Capacitors
Note: C21, C22, and C23 are polarized electrolytic caps. Verify proper polarity before
you solder.
Designation Value Description Done

C21
220 µF
Electrolytic
, 35 Volt
, watch polarity
C22
220 µF
Electrolytic, 35 Volt, watch polarity
C23
220 µF
Electrolytic, 35 Volt, watch polarity
Install the Sockets, Integrated Circuits and Transistor
Install the 8-pin DIP IC sockets. Align the half-moon feature of the socket with the notch
in the PCB silkscreen.
Designation Value Description Done

U2
socket
8 pin socket for Dual Opamp
U3
socket
8 pin socket for Dual Opamp
U4
socket
8 pin socket for Dual Opamp
U5
socket
8 p
in socket for Dual Opamp
U6
socket
8 pin socket for Dual Opamp
Figure 36-Remember to match silk screen and IC orientation mark
Install U7, the motor driver for the balance and volume pots. As in previous IC
installation steps:
 Get the IC in the right way by matching silk screen and IC orientation marks
 Bend two corner pins to retain the IC until you solder it in place. Choose places to
bend the pins that avoid shorting traces together.
Designation Value Description Done

U7
SN754410
Dual H
-
Driver
