Section 6: Assembling the Input Selector Board
Carefully empty the contents of the envelope marked “PR-101 Input Selector” into a
broad soup bowl.
Figure 29-Silkscreen side of the Input Selector Board shows component locations
Install the Resistors
Install the resistors using the same procedures outlined in the previous section. If you’re
using a lead bending jig, all the resistors should be bent at a width of 0.45”.
Designation Value Color Code Done
R25
100K
Brown, black, black, orange, brown
R26
100K
Brown, black, black, orange, brown
R27
100K
Brown, black, black, orange, brown
R28
100K
Brown, black, black, orange, brown
R29
100K
Brown, black, black, orange, brown
