34
Transmitter
Output Power (±1 dB) W 1
0 / 25 (depending on the version)
Spurious Emissions µW from 9 KHz to 1 GHz < -36 dBm
from 1 to 4 GHz < -30 dBm
Modulation System - F
M (F3E) / PM (G3E)
Maximum Deviation KHz ± 2.5 (@ 12.5 KHz) / ±5 (@ 25 KHz)
Adjacent Channel Power Attenuation dB < -60 (@ 12.5 KHz) / -70 (@ 20-25 KHz)
Receiver
Configuration Double Conversion Superetherodyne
Sensitivity (at 12 dB SINAD) µV < 0.3
Squelch Sensitivity (SINAD) µV 0.25 with 3 dB hysteresis
Selectivity (Adjacent Channel) dB At least -60 (@ 12,5 KHz) / -70 (@ 25 KHz)
Spurious Response Rejection dB > 70
Intermodulation dB > 65
Audio Output (1 KHz at 5% T.H.D.) W 4
(built-in internal speaker) / 10 (external audio output)
Mechanical Specifications
Type of construction - M
etallic cabinet with detachable front panel
Size mm 180x57x28 with front panel / 174x48x150 main unit only
Weight Kg 1.4
Microphone connector - R
J
Rear I/O connector - 2
5-pins DB type
Shock resistance - M
eets MIL STD 810 specifications
Moisture & Dust Resistance - A
ccording to the IEC529 and IP54 regulations
Technical specifications
