Technical specifications
14 TECHNICAL SPECIFICATIONS
14.1 Test methods
• ETS 300-086 / ETS 300-113 (optional “modem board”)
• IEC 529 IP54 and MIL STD 810 C/D/E
14.2 Specifications table
General
Characteristic Units Value/Measurements conditions
Frequency MHz from 136 to 174
Operating Band MHz 38
Number of Programmable Channels - u
p to 100
Channel Spacing KHz 12.5 / 20 / 25
Frequency Steps KHz 5 / 6.25
Rated Power Supply Vdc 13.8
Current drain A S
tand-by 0.4 (or less)
RX 0.6 @ the maximum AF power
TX 5 (@ 25 W) / 3.5 (@ 10 W) / 2.4 (@ 4 W)
Antenna Impedance Ohm 50
Speaker Impedance Ohm 8
F
requency Stability ppm ±5
Operating Temperature Range °C from –25 to +55
Relative Humidity % 9
0 (non condensing)
