6 — ONT management using an ONT interface
6-68 March 2011 Alcatel-Lucent 7330/7302 ISAM FTTN R04.02.42a
ONT Product Information Guide Edition 01 3FE 54199 AAAA TCZZA
6.15 XML file configuration data for package C ONTs
For ONTs that are shipped with an XML file already configured, the data that defines
L3 interface and WiFi behavior is pre-configured with default values. Use an XML
file editor to update the file to meet WiFi requirements. See the appropriate unit data
sheet for more information. Table lists the XML file configuration options, sample
XML, and parameter ranges.
Table 6-11 XML file configuration data for package C ONTs
XML parameter Parameter values Sample XML Information
WAN interface configuration
instanceID Specifies the instance ID. Set to 1 and
cannot be changed
<Layer3>
<WANInterface
NumberOfInstance="1"
MaxNumber="1">
<WANInterfaceConfig
InstanceID="1"
WANName="wan1"
IpGetMode="static"
IpAddress="222.10.60.88"
SubMask="255.255.255.0"
PPPoEUserName=""
PPPoEUserPasswd=""
Gateway="222.10.60.254"
DNSDomainName="tele.com"
DNSServer1="210.11.123.13"
DNSServer2="210.11.123.13"
WANID="1"/>
</WANInterface>
—
WANName Specifies the WAN name, an alphanumeric
string of 1 to 256 characters
—
IpGetMode Specifies the method used by the device to
retrieve its IPv4 address. The options are:
• static
• dhcp
• pppoe
Use standard
IPv4 addressing
for static.
IpAddress Specifies the IPv4 address in dotted decimal
notation format. Can be configured when
IpGetMode is set to static.
—
PPPoEUserName Specifies the user name for the PPPoE
connection. Can be configured when
IpGetMode is set to pppoe.
—
PPPoEUserPasswd Specifies the user password for the PPPoE
connection. Can be configured when
IpGetMode is set to pppoe.
—
Gateway Specifies the IPv4 address of the network
device when the default IP address does not
match any routing table routes. Can be
configured when IpGetMode is set to dhcp
—
dnsdomainname Specifies the DNS domain name of the DHCP
gateway device. Can be configured when
IpGetMode is set to dhcp
—
DNSServer1 Specifies the DNS primary server IP address
for the DHCP gateway device. Can be
configured when IpGetMode is set to dhcp
—
DNSServer2 Specifies the DNS secondary server IP
address for the DHCP gateway device. Can
be configured when IpGetMode is set to
dhcp
—
LAN type
(1 of 5)
