3.3.5.
HTTP(S)
Method 1 – Manual
1- Power on the phone.
2- At the phase 2/5 network setup, press the "i" key and just after the "#" key.
3- ‘MAC address’ menu is displayed.
4- Scroll down to ‘IP parameters’.
5- Press OK.
6- Set following parameters (OK to select or change value).
IP Mode: Static
IP @: @ you want to give to your SIP phone
Subnet: Subnet mask
Router: Default gateway of your subnet
DL scheme (download scheme): HTTP or HTTPS
Use default port: Yes
DL @: HTTP(S) Server @
DL port: 80 (443)
DL Path: The path to the directory where Configuration and Binaries are located
7- Press OK to save.
Warning: no administrator action within 30 seconds in the configuration menu will automatically
lead to quit this menu.
