Alcatel-Lucent OmniAccess 4504 - Specifications, Safety & Compliance; Physical Specifications; Power Management Specifications; Operating Specifications

OmniAccess 4504, 4604, and 4704 WLAN Switch | Installation Guide Specifications, Safety & Compliance | 17
Appendix A
Specifications, Safety &
Compliance
Specifications
Physical Specifications
z Device Dimensions (without rack mount brackets) (HxWxD):
 All Models: 1.75” x 13.8” x 11.7”
 All Models: 44 mm x 351 mm x 297 mm
Device Weight (with rack mount brackets):
z OAW-4504: 7.1 lbs/3.2 kgs
z OAW-4604/OAW-4704: 7.4 lbs/3.4 kgs
z Shipping Dimensions (HxWxD):
 All Models: 6.5” x 18.2” x 16.5”
 All Models: 165 mm x 462 mm x 419 mm
z Shipping Weight:
 OAW-4504: 9.4 lbs/4.3 kgs
 OAW-4604/OAW-4704: 9.7 lbs/4.4 kgs
Power Management Specifications
Power Consumption
z OAW-4504: 35 W maximum
z OAW-4604: 45 W maximum
z OAW-4704: 60 W maximum
Power Specifications (AC Input Requirements)
z OAW-4504:
 AC Input Voltage: 90-264 V~, Universal Input
 AC Input Current: 1.5 A
 AC Input Frequency: 47-63 Hz
z OAW-4604/OAW-4704:
 AC Input Voltage: 90-264 V~, Universal Input
 AC Input Current: 2.2 A
 AC Input Frequency: 47-63 Hz
Operating Specifications
z Operating Temperature Range: 0°C to 40°C (32°F to 104°F)
z Operating Humidity Range: 5% to 95% (RH), non-condensing
