Network Port Status LEDs (OS6900-Q32 and OS6900-X72 Switches)
Because OS6900-Q32 and OS6900-X72 models provide splitter cable support on selected QSFP+ ports
(see page 3-6 and page 3-12), port LED behavior for these switches differs from other OS6900 models.
While it is important to note all details listed in the table below, general “at-a-glance” associations can be
made when viewing LED colors. E.g., green typically indicates 40G (non-VC); yellow indicates 4X10G
(non-VC) and blue indicates 40G or 4X10G in a VC configuration. More detailed port LED behavior is
described below.
* Refer to “4X10G Splitter Cable LED Indicators” on page 3-27.
Note. To manually configure network LED colors on OS6900-Q32 and OS6900-X72 switches, refer to the
interfaces beacon command in the OmniSwitch AOS Release 8 CLI Reference Guide.
LED Display
Admin
Status
Link Status Transceiver Traffic VFL
Port Speed
1G/10G (SFP+)
40G/4X10G (QSFP+)
Off Down Down N/A N/A N/A N/A
Off Up Down No N/A N/A N/A
Solid Green Up Up Yes No No
10G (SFP+; Q32 Only)
40G (QSFP+)
Solid Yellow Up Up Yes No No
1G (SFP+; Q32 Only)
4X10G (QSFP+)
Solid Blue Up Up Yes No Yes N/A
Blinking Green Up Up Yes Yes No
10G (SFP+; Q32 Only)
40G (QSFP+)
Blinking Yellow Up Up Yes Yes No
1G (SFP+; Q32 Only)
4X10G (QSFP+)
Blinking Blue Up Up Yes Yes Yes N/A
White* N/A N/A Yes N/A N/A 4X10G
