80V Lithium-Ion 20” Brushless Lawn Mower
AFTER SALES SUPPORT
e-mail: info.aldi@positecgroup.com
1300 889 028
MODEL: №. 10094 • 08/2019 • CLM80XA
(toll free)
14
4) Push the outer locking lever (5) upwards
towards the upper handle (2). (See Fig. B4)
5) Continue to turn the outer locking lever (5)
clockwise to secure the handles in place. Be sure
to turn the outer locking lever (5) in an upwards
direction to secure. (See Fig. B5)
6) Repeat step 2 to 5 to the other side of the upper
handle (2). Check to ensure the upper handles are
locked in place.
7) Attach the 4 cable clips (17) onto the upper
handle (2) to x the cables in position. (See Fig. B6)
NOTE: Place the cable into the protruding ring of
the cable clip (17).
Installing the grass collection bag (16)
WARNING: Before installing, make sure
the mower is switched o, the battery
pack is removed, the blades have come to a
standstill, and the engine is cooled.
1) Raise the rear discharge guard (15) and hold it
up, remove the mulching block (21) if it is in the
rear chute. (See Fig. C1)
B2.
B3.
B4.
C1.B6.B5.
