80V Lithium-Ion 20” Brushless Lawn Mower
AFTER SALES SUPPORT
e-mail: info.aldi@positecgroup.com
1300 889 028
MODEL: №. 10094 • 08/2019 • CLM80XA
(toll free)
20
NOTE:
• The start bar (3) must be held rmly against the foam grip upper handle
(2) bar to both start the mower and to keep the mower running. Releasing
the start bar (3) will stop the mower.
• In case of an emergency, release the start bar (2) immediately to switch o
the mower.
- Stopping
Release the start bar (3) to stop the mower. Wait until the motor is fully
switched o.
Operating
WARNING: Keep hands, feet, hair and clothing away from all the
moving parts of the lawn mower. Make sure that the blade (23) is
securely fastened before starting the mower.
NOTE: For starting, ensure the lawn mower is set to the highest height
setting so the blades (23) are not resting deep into the grass.
This lawn mower has the option to be manually pushed or motor driven self
propelled when the motor is running.
- Manual operation
The lawn mower can be manually operated under the user’s own power
when the mower is operating. i.e. the user is pushing
the lawn mower forwards or backwards. To operate
this way, after pressing the lock o button (18), ONLY
pull the start bar (3) towards the upper handle (2)
bar and leave the self propel engagement bar (1) in
its original position. (See Fig. J1) Release the lock o
button (18) and start operating the mower.
- Self propelled operation
The self propelled operation will only operate when
the motor is running. To operate this way, after
pressing the lock o button (18), pull the start bar (3)
towards the upper handle (2) bar rst and then pull
the self propel engagement bar (1) upwards towards
the upper handle (2) bar also. (See Fig. J2) Hold them
in position and the mower will move forward itself
with the operator steering and directing using the
handlebars.
To stop the self-propelled operation, just release the
self propel engagement bar (1) to its original position,
J1.
J2.
