31
Using for the first time
5. Secure the middle struts to the legs using two lock bolts (
23
),
two small washers (
27
), two spring washers (
24
) and two hex
nuts (
29
) on each.
6. Now tighten all the screw connections.
7. Then plug one rubber foot (
11
) onto each leg (
8
).
8. Then fit one tilt guard (
10
) to each of the rear legs using two
hexagon screws (
24
), spring washers (
26
), small washers
(
27
) and hex nuts (
29
) each.
Fitting the table width extension (Fig. 12)
1. To be able to fit the table width extension (
7
), remove the
screw ( A ) on both undersides of the guide tubes.
2. After undoing the two knurled screws (
30
), you can slide the
table width extension into the opening.
3. Now fit the screw ( A ) back in the guide tube. This serves as an
end stop.
4. You can use the knurled screw (
30
) to adjust the width of the
table width extension on an infinitely adjustable basis as far as
the end stop.
5. Carefully turn the saw table over and set it down with its legs on
the floor.
Fitting/adjusting the splitter (Figs. 14-19)
Risk of injury!
If the table saw is started up by accident or the saw blade is handled
incorrectly, there is a risk of serious injuries.
• Always pull the power plug from the socket outlet before making
adjustments to the table saw.
• Always wear protective gloves when handling the saw blade or
working in its immediate vicinity. Check the splitter (
4
) every
time after you have changed the saw blade and align it correctly if
Layout_F_TS_2000_1_UK_SPK7.indd 31Layout_F_TS_2000_1_UK_SPK7.indd 31 23.06.2020 14:29:3723.06.2020 14:29:37
