Using for the first time
necessary.
1. Make sure that the saw blade (
30
) is lowered to the maximum in
the saw table (
1
). To lower the saw blade if necessary, turn the
crank (
32
) counterclockwise as far as the stop.
2. Remove the two fastening screws and remove the table insert
(
5
) from the saw table. When you do so, always check the table
insert: Replace the table insert immediately if it is damaged or is
no longer flush with the saw table.
3. Make sure that the angle adjustment facility of the saw blade
is set to 0°. If necessary, adjust the angle adjustment facility as
described in the section “Setting the cutting angle”.
4. To turn the saw blade out of the saw table as far as the maximum,
turn the crank clockwise as far as the stop.
5. Undo the clamping screw (
33
) using a size 10 wrench (
12
) by
turning it several revolutions counterclockwise.
6. Insert the splitter behind the clamping plate (
34
)and push it
down to the maximum.
7. Turn the clamping screw several revolutions clockwise to screw it
tight.
8. Align the splitter so that there is a gap of 3-5 mm to the saw blade
at all points.
9. Secure the splitter by turning the clamping screw clockwise again
to tighten it.
10. To turn the saw blade into the saw table as far as the maximum,
turn the crank counterclockwise as far as the stop.
11. Pull the table insert slightly apart and push it over the laser and
splitter again. Insert the lug on the rear end of the table insert
into the corresponding groove on the saw table and then lower
the front end.
12. Check that the table insert is secure: The table insert must be
flush with the saw table.
