36
Operation
2. Slacken the knurled nuts on the parallel stop (
20
) by turning
them several revolutions.
3. Move the stop rail until the rear end of the stop rail touches the
imaginary 45° line.
4. Tighten the knurled nuts again.
Cross stop
Do not push the stop rail of the cross stop too far toward the saw
blade. The distance between the stop rail and the blade should be
approx. 2 cm.
1. Slide the stop rail (
17
) onto the cross stop (
15
) so that the
square necks of the two lock bolts slide into the profile of the stop
rail.
2. Secure the stop rail on the cross stop by tightening the two
knurled nuts.
3. Slide the guide rail system (
18
) of the cross stop into the guide
grooves (
6
) of the saw table.
4. Slacken the knurled screw (
16
) and turn the cross stop until the
line on the guide rail system coincides with the required angular
setting.
5. Tighten the knurled screw again.
Laser (Fig. 24)
With the help of the laser (
3
), you can perform precision cutting
work with your table saw.
The laser light is generated by a laser diode. The laser light is
enlarged to form a line and is emitted through the laser emission
aperture. You can then use the line as an optical marker of the
sawing line for precision cuts. It is important that you obey the safety
instructions for the laser.
Switching on the laser:
Set the laser switch (
41
) to “ON”. When the saw blade guard is
fitted, the laser switch can be accessed through the opening on the
Layout_F_TS_2000_1_UK_SPK7.indd 36Layout_F_TS_2000_1_UK_SPK7.indd 36 23.06.2020 14:29:3723.06.2020 14:29:37
