37
Operation
top. A red laser beam will now be projected from the laser emission
aperture. If you guide the laser beam along the sawing line mark as
you saw, you will produce clean, precise cuts.
Switching off the laser:
Set the laser switch (
41
) to “OFF”.
The laser beam will go out.
Always switch off the laser when not in use in order to save the
batteries.
The laser beam can be blocked by deposits of dust and chips. You
should therefore remove these particles from the saw blade guard
each time after use.
Inserting/changing the laser batteries (Fig. 11)
The laser beam shows you exactly where the saw blade (
31
) will be
cutting next and therefore enables you to achieve extremely precise
cuts.
For the operation of the laser (
3
) you require two type 1.5 V
AAA/LR03 batteries (supplied with the product), which are inserted/
changed as follows:
1. Set the laser switch (
41
) to position 0 (laser off).
2. Swing the saw blade guard (
2
) up as shown in Fig. 24.
3. Flip the battery compartment cover (
42
) up and remove it.
4. Remove the old batteries from the battery compartment if
necessary. Please observe the instructions in the section
“Disposal”.
5. Insert the new batteries, ensuring that you fit them the right
way round according to the polarity shown in the battery
compartment.
6. Replace the battery compartment cover.
7. Swing the saw blade guard (
2
) down again.
Layout_F_TS_2000_1_UK_SPK7.indd 37Layout_F_TS_2000_1_UK_SPK7.indd 37 23.06.2020 14:29:3723.06.2020 14:29:37
