Air Filter
It is very important to maintain an air filter (21) in proper condition. Damage to
the generator may arise if the filter has:
installation and engine wear.
It is recommended the air filter (21) is cleaned every 50 hours (every 10 hours
under dusty conditions).
ALWAYS keep the filter clean at all times.
WARNING: Ensure the engine is switched off while undertaking this task.
1. Remove the air filter cover (20) on the side of the generator using the
supplied 10mm tube spanner (30) by removing (unscrewing) the two
screws on the face of the cover, in an anti-clockwise direction (Fig AA).
2. Remove the air filter (21) (Fig AB).
3. Wash the air filter (21) in hot soapy water and allow to dry.
4. Lubricate the air filter (21) using engine oil (SAE 10W-30).
5. Thoroughly squeeze the air filter (21) removing any excess oil.
6. Replace the air filter (21).
7. Secure the air filter cover (20) back on to the side panel of the air filter
housing using the supplied 10mm Tube Spanner (30) by screwing back in
the two screws in a clockwise direction until secure.
IMPORTANT. Never run the engine without the air filter element in place.
CAUTION: Never use fuel or low burning paint solvents to clean the air filter
(21). A fire or explosion could result.
CAUTION: Ensure the air
filter (21) is dry before re
fitting.
Replacement air filters
are available from www.
extrabattery.com.au or by
calling Customer Service
on 1800 909 909.
Maintenance
AB.AA.
