Drawing/Parts list
Item Qty. Denomination
1 1 End cap
2¨ 2 O-ring
3 1 Cylinder
4¨ 1 Lock wire
5¨ 1 O-ring
6 1 Piston
7¨ 1 O-ring
8 1 Bonnet
9 2 Plug
10 1 Spring packet standard (black)
1 Extra strong spring alternative
(white)
11¨1Clip assembly
14D 1 Lip seal
15 2 Clamp half with screw
(stop valve)
4 Clamp half with screw
(change-over valve)
18 1 Valve body, lower
19 1 Valve plug, single, complete
19a 1 Stem
19eD 1 Seal ring
19f 1 Washer
19gD1O-ring
19h 1 Screw
D : Service kit - EPDM, NBR, FPM
(See Spare Parts List)
¨ : Only for NO - and NC actuators.
The drawings and the parts list include all items.
NO = Normally open.
NC = Normally closed.
The items are identical with the items in the Spare Parts
List.
When ordering spare parts, please use the Spare Parts
List!
Parts list
SRC - stop valve 38mm - 101.6mm
