8128 SIP Strobe Light (G2)
Specifications
Power Input: 48V PoE IEEE 802.3af Class 0 (Max 12.95 W)
Strobe Triggers: SIP extension ring, Subscribe/Notify, multicast, dry
SIP: Multiple extensions for Page or Alerting
Audio Memory: 1 GByte available
Relay Output: Normally open, activated when 8128 is in use
Max 30 V 50 mA
Relay Input: Normally open or normally closed dry contact,
Algo 1202 Call Box, Algo 1203 Wall Switch, EOL
termination
Flash Patterns: 11 Selectable Patterns
Relay Input Current
Draw Detection
Thresholds:
Active Idle Tamper
Normally Open >4mA <4mA N/A
Normally Open
with Supervision
>20mA 4-20mA <4mA
Normally Closed <4mA >4mA N/A
Normally Closed
with supervision
4-20mA >20mA <4mA
Nominal 12V source, current limited to 40mA
Typical supervision resistor value = 1k ohm
Configuration: Web interface or provisioning
Provisioning: TFTP, FTP, HTTP, HTTPS
Supervision: SNMP
NAT: STUN, CRLF Keep Alive
Processor: Linux OS ARM Cortex-A8 32-Bit RISC Processor
Environmental: -20°C to +50°
C; 10-95% RH non-condensing. Dry indoor
location only unless wiring cavity protected from water
ingress.
Compliance: EN60950:2001, IEEE 802.3-2008, RFC3261, RoHS,
CE, FCC, CSA (USA & Canada)
Document 90-00100C
11/27/2019
Page 53
