Alienware Alpha R2 - Page 32

3 Turn the chassis over and remove the antenna cable from the routing guides on the
power-button module.
1 power-button board cable 2 routing guides
4 Use a plastic scribe to release the tabs at the bottom of the power-button module
from the slots on the chassis.
32
