Alienware Alpha R2 - Post-Requisites

2 Align the captive screws on the processor heat sink with the screw holes on the
system board.
1 processor heat sink 2 captive screws
3 system board 4 back panel
3 Tighten the captive screws that secure the processor heat sink to the system board.
Post-requisites
1 Replace the processor fan.
2 Replace the top cover.
3 Replace the base cover.
43
