Alienware Alpha R2 - Replacing the Front-panel Light Board

Replacing the front-panel light board
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Procedure
1 Align the tabs on the front-panel light module with the slots on the front panel, and
snap the front-panel light module onto the front panel.
2 Route the front-panel light board cable through the cable-routing hole on the
chassis.
3 Connect the front-panel light board cable to the system board (LOGOCON).
Post-requisites
1 Replace the video-card fan.
2 Replace the top cover.
3 Replace the base cover.
63
