2 Remove the jumper plug.
1 jumper plug 2 password jumper (Pin number
three and four)
3 Replace the processor fan.
4 Replace the top cover.
5 Replace the base cover.
6 Turn on your computer and wait till the operating system is completely loaded.
7 Shut down your computer.
8 Remove the base cover.
9 Remove the top cover.
10 Remove the processor fan.
11 Replace the jumper plug on the password jumper (pin number three and four).
Post-requisites
1 Replace the processor fan.
88
