38 | Removing the Processor Module
Removing the Processor
Module
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
"Before You Begin" on page 9. For additional safety best practices
information, see the Regulatory Compliance Homepage at dell.com/
regulatory_compliance.
Prerequsites
CAUTION: To prevent intermittent contact between the ZIF-socket
cam screw and the processor module when removing the processor,
press to apply slight pressure to the center of the processor module
while turning the cam screw.
CAUTION: To avoid damage to the processor module, hold the
screwdriver so that it is perpendicular to the processor module when
turning the cam screw.
1 Remove the battery pack. See "Removing the Battery Pack" on page 12.
2 Remove the compartment door. See "Removing the Compartment Door" on page 14.
3 Remove the processor heat-sink fan. See "Removing the Processor Heat-Sink Fan" on
page 29.
4 Remove the processor heat-sink. See "Removing the Processor Heat-Sink" on
page 35.
Procedure
1 To loosen the ZIF socket, use a small, flat-blade screwdriver and rotate the ZIF-socket
cam screw counterclockwise until it comes to the cam stop.
CAUTION: To ensure maximum cooling for the processor module, do
not touch the heat transfer areas on the processor thermal cooling
assembly. The oils in your skin can reduce the heat transfer capability
of the thermal pads.
CAUTION: When removing the processor module, lift the module
straight up. Be careful not to bend the pins on the processor module.
