Removing the Center Control Cover | 41
Removing the Center Control
Cover
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
"Before You Begin" on page 9. For additional safety best practices
information, see the Regulatory Compliance Homepage at dell.com/
regulatory_compliance.
Prerequsites
1 Remove the battery pack. See "Removing the Battery Pack" on page 12.
2 Remove the compartment door. See "Removing the Compartment Door" on page 14.
Procedure
1 Remove the screws that secure the center control cover to the computer base.
CAUTION: Be extremely careful when removing the center control
cover. The cover along with the cable that attaches to it are fragile.
2 Turn the computer over and open the display as far as possible.
1 screws (5)
