Replacing the Bluetooth Card | 69
Replacing the Bluetooth Card
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
"Before You Begin" on page 9. For additional safety best practices
information, see the Regulatory Compliance Homepage at dell.com/
regulatory_compliance.
Procedure
1 Align the screw hole on the Bluetooth card with the screw hole on the system board.
2 Replace the screw that secures the Bluetooth card to the system board.
3 Connect the Bluetooth-card cable to the connector on the system board.
Postrequsites
1 Replace the palm rest assembly. See "Replacing the Palm Rest Assembly" on page 66.
2 Replace the status light board. See "Replacing the Status Light Board" on page 63.
3 Replace the display assembly. See "Replacing the Display Assembly" on page 60.
4 Replace the power button board. See "Replacing the Power Button Board" on
page 56.
5 Replace the keyboard. See "Replacing the Keyboard" on page 48.
6 Replace the center control cover. See "Replacing the Center Control Cover" on
page 44.
7 Replace the compartment door. See "Replacing the Compartment Door" on page 15.
8 Replace the battery pack. See "Replacing the Battery Pack" on page 13.
9 Follow the instructions in "After Working Inside Your Computer" on page 11.
