44 | Replacing the Center Control Cover
Replacing the Center Control
Cover
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
"Before You Begin" on page 9. For additional safety best practices
information, see the Regulatory Compliance Homepage at dell.com/
regulatory_compliance.
Procedure
1 Connect the media control keys cable to the connector on the system board.
2 Align the tabs on the center control cover with the slots on the palm rest assembly
and snap the center control cover into place.
3 Close the display and turn the computer over.
4 Replace the screws that secure the center control cover to the computer base.
Postrequsites
1 Replace the compartment door. See "Replacing the Compartment Door" on page 15.
2 Replace the battery pack. See "Replacing the Battery Pack" on page 13.
