ALLEN & HEATH ML3000 Service Manual

12 ML3000 Service Manual
Installation Details
Weights 24 Channel 34 kg (75 lbs)
32 Channel 41 kg (90 lbs)
40 Channel 48 kg (106 lbs)
RPS11 psu 9.5 kg (21 lbs)
Refer to the power supply user guide
for safety and installation instructions.
Heed all warnings printed in the user
guide and on the power unit.
Refer to the RPSD2 user guide for
instructions on linking two RPS11
power supplies for redundant supply
backu
p
.
110
640
252
LAMP SOCKETS
PHONES SOCKET
ML3000-40 = 1651
ML3000-32 = 1396
ML3000-24 = 1141
482.6
134
417
FC 57
229
(3U)
