22 ML3000 Service Manual
ORDERING AN ASSEMBLY
The following assemblies for the ML3000 are supplied fully tested. Please quote the description and
order code for the part required.
Printed circuit board (PCB) assemblies:
DESCRIPTION ORDER CODE
Mono Input PCB assembly 002-742
Stereo Input PCB assembly 002-746
Master Connector PCB assembly 002-750
Group / Aux PCB assembly 002-743
Aux Matrix PCB assembly 002-744
Master Distribution PCB assembly 002-778
SYS-LINK 2 In PCB assembly 002-634
MIDI Power PCB assembly 002-753
CPU PCB assembly 002-550
LCR PCB assembly 002-752
Master / Stereo Fader PCB assembly 002-748
Master PCB assembly 002-745
Mono Fader PCB assembly 002-747
Mono Connector PCB assembly 002-749
SYS-LINK 2 Out PCB assembly 002-636
Meter Master PCB assembly 002-755
Meter 1-8 & 9-16 V2 PCB assembly 002-716
Meter LEDBAR PCB assembly 002-754
IDC connector harnesses:
DESCRIPTION
ORDER CODE
GL4000-Master harness AL2759
10 way Master to rear harness AL4605
16 way LRC to rear harness AL4606
10 way LRC Fader harness AL4607
26 way Mono Fader harness AL4608
34 way MPC to Master Fader harness AL4609
10 way Master to Master Fader harness AL4610
26 way CPU to PSU (Power) harness AL4611
10 way CPU to PSU (MIDI) harness AL4612
ML3-40 26 way Main harness AL4613
ML3-24 26 way Main harness AL4617
ML3-32 26 way Main harness AL4618
10 way Dist. to rear Connector harness AL4624
16 way Master Interconnect harness AL4625
