ALLEN & HEATH ML3000 Service Manual

26 ML3000 Service Manual
SWITCH 4PCO LATCH AL0333 10
JUMPER SOCKET 2WAY AL0334 15
SWITCH ALPS 2PCO MOM AL0374 10
FLEX SKT 12WAY 90DEG AL2226 5
FLEX SKT 12WAY STRT AL2227 5
XLR FEM 3PIN VERT PCB AL2410 5
XLR MALE 3PIN VERT PCB AL2411 5
SWITCH SLIDE MINI SPDT PCB AL3081 2
JACK SKT 1/4" ST V MET UNSW AL3407 5
JACK SKT 1/4" ST V MET AL3410 10
CRIMP TERMINAL RING 4BA INSUL AL3449 5
MOLEX 0.1" MALE 10X2PIN STRT AL3451 5
MOLEX 0.1" MALE 5X2PIN 90DEG AL3512 5
BOX HEADER 0.1" 26WAY 90DEG AL3592 5
FLEX SKT 15WAY 90DEG AL4076 5
MOLEX 0.1" MALE 5WAY 90DEG LCK AL4270 5
TERMINAL SCREW PCB MOUNT AL4303 5
MOLEX 0.1" FEM 5X2PIN STRT AL4306 5
MOLEX 0.1" MALE 5WAY STRT LCK AL4594 5
WFM ASSY ML3 FADER AL4619 10
SWITCH ALPS 2PCO LATCH 90DEG AL8065 5
LEDs and Semiconductors:
DESCRIPTION ORDER CODE QTY
DIODE 1N4148 SIGNAL AE0007 25
TRANSISTOR BC549 NPN AE0020 10
TRANSISTOR BC214C PNP AE0031 2
IC TL072 OP-AMP AE0046 25
IC LM339N COMPARATOR AE0071 5
TRANSISTOR J111N FET T092B AE0083 10
LED T1 3MM YELLOW AE0084 10
LED T1 3MM GREEN AE0085 10
LED T1 3MM RED AE0086 10
IC CMOS 4053B - CD4053BCN AE0117 1
IC CMOS 4051B - CD4051BCN AE0118 2
IC NE5532N OP-AMP AE0221 20
IC 6N136 OPTO-ISOLATOR AE0222 1
IC REGULATOR 7805 AE0308 1
IC CMOS 74HC165 AE2749 1
IC CMOS 74HC4094N AE2755 2
IC LM393N COMPARATOR AE2818 5

ALLEN & HEATH ML3000 Specifications

General

Type	Analog Mixing Console
Faders	100mm
Group Buses	8
Main Outputs	2
Signal to Noise Ratio	> 90 dB
Output Impedance	75 Ω
EQ	4-band EQ with 2 sweepable mids
Frequency Response	20 Hz to 20 kHz
Input Impedance	10 kΩ
