Playback –
• Touch the ‘Stereo Playback’ file name value. Then touch the ‘Playback’ or
‘Recording’ button to view files in each folder (recordings you have made with
the SQ are displayed in the ‘Recordings’ folder).
• Touch a track to highlight it.
• Touch the ‘Select’ button to load the highlighted track.
• Touch the ‘Playback Mode’ value to select a mode.
Play All = Play all tracks in the folder consecutively.
Play Single = Play the selected track then stop.
Repeat All = Repeatedly play all tracks in the folder consecutively.
Repeat Single = Repeatedly play the selected track.
• Touch the transport buttons to go to the previous or next track, or to stop or
play/pause.
• Touch and drag the circular playback position marker to jump to a different point
in the track.
Formats and Folders –
SQ-Drive stores stereo recordings to ‘<SQ-DRIVE>:\AHSQ\USBREC’.
These are 96kHz or 48kHz 24bit stereo *.wav files, named sequentially in the order
recorded i.e. SQ-ST001.WAV, SQ-ST002.WAV…
Files for stereo playback copied from a computer should be placed in
‘<SQ-DRIVE>:\AHSQ\USBPLAY’.
These can be mono or stereo, uncompressed PCM *.wav files, 44.1, 48 or 96kHz and
16 or 24-bit.
They must not contain any headers (such as BWF) or data (such as markers).
Length of Recording –
The maximum length of a stereo recording is approximately 2 hrs and will use around
4GB of storage.

ALLEN & HEATH SQ-6 Specifications

General

Channels quantity	48 channels
Supported sample rates	96 kHz
Digital sound processing	- bit
DJ mixer	-
Product color	Black
Output impedance	75 Ω
MIDI out	Yes
RJ-45 ports quantity	1
Power consumption (typical)	- W

Weight and Dimensions

Depth	514.9 mm
Width	638 mm
Height	198 mm
Weight	14500 g
Package depth	680 mm
Package width	820 mm
Package height	360 mm
Package weight	17300 g
