62 Rockwell Automation Publication 1420-UM001E-EN-P - March 2016
Appendix A PowerMonitor 500 Unit Data Tables
312814 1 Reset W L1 UINT 16 Bit0 = 1: Reset Max Value
Bit1 = 1: Reset DMD value
Bits 2 … 15: Reserved
312815 1 Reset W L2 UINT 16
312816 1 Reset W L3 UINT 16
312817 1 Reset W UINT 16
312818 1 Reset VA L1 UINT 16
312819 1 Reset VA L2 UINT 16
312820 1 Reset VA L3 UINT 16
312821 1 Reset VA UINT 16
312822 1 Reset VAR L1 UINT 16
312823 1 Reset VAR L2 UINT 16
312824 1 Reset VAR L3 UINT 16
312825 1 Reset VAR UINT 16
312826 1 Reset PF L1 UINT 16
312827 1 Reset PF L2 UINT 16
312828 1 Reset PF L3 UINT 16
312829 1 Reset PF UINT 16
312830 1 Reset Hz UINT 16
313569 1 Reset Total kWh+ UINT Value=1 - command executed
313570 1 Reset Total kVARh+ UINT Value=1 - command executed
313571 1 Reset Total kWh- UINT Value=1 - command executed
313572 1 Reset Total kVARh- UINT Value=1 - command executed
313573 1 Reset Partial kWh+ UINT 16 Value=1 - command executed
313574 1 Reset Partial kVARh+ UINT 16 Value=1 - command executed
313575 1 Reset Partial kWh- UINT 16 Value=1 - command executed
313576 1 Reset Partial kVARh- UINT 16 Value=1 - command executed
Table 32 - Commands: Write-only
Modbus
Address
Length
(words)
Description / Units Data Format Notes
