130 Rockwell Automation Publication 1734-UM013N-EN-P - September 2017
Chapter 6 Configure the Module for a SmartGuard Controller
4. To add a safety connection, from the Connection Name pull-down menu,
choose one of these options.
The more status that is read, the larger the packet size.
5. From the Connection Type pull-down menu, for this example choose
Multicast.
6. From the Configuration pull-down menu, for this example choose
Configuration signature must match.
Choose Description
1734-IB8S
[IN] Safety Control of safety inputs
[IN] Safety +
Combined Status
(1)
- Muting
Control of safety inputs
Status combined into 1 bit for all inputs
Muting status is available
[IN] Safety + Pt. Status Control of safety inputs
Individual status for each input point
[IN] Safety + Pt. Status -
Muting
Control of safety inputs
Individual status for each input point
Muting status available
[IN] Safety + Pt. Status-
Muting - Test Output
Control of safety inputs
Individual status for each input point
Muting status available
Test output status available
[OUT] Test Control of test outputs
1734-OB8S
[IN] Safety Monitor -
Combined Status - Power
Monitor safety outputs
Status combined into 1 bit for all outputs
Power status available
[IN] Safety Output Status Individual status for each output point
[IN] Safety Output Status+
Monitor
Individual status for each output point
Monitor safety outputs
[OUT] Safety Control of safety outputs
1734-OBV2S
[IN] Safety Monitor -
Combined Status - Power
Monitor safety outputs
Status combined into 1 bit for all outputs
Power status available
[IN] Safety Output Status Individual status for each output point
[IN] Safety Output Status+
Monitor
Individual status for each output point
Monitor safety outputs
[OUT] Safety Control of safety outputs
1734-IE4S
(2)
[IN] Channel and Combined
Alarm Status
Combined channel status and alarm status for each input point
[IN] Channel Status, Alarm
Status
Individual status for each input point
Combined alarm status for each input point
Power status
[OUT] Tach Reset Resets a latched overfrequency condition and enables the module to
begin to calculate frequency again.
(1) Most digital input connections use Combined Status.
(2) Other connection options are available via RSNetWorx for DeviceNet software, but their use with a SmartGuard controller
is not recommended.
