Allen-Bradley 1734-OB8S User Manual

Rockwell Automation Publication 1734-UM013N-EN-P - September 2017 137
Configuring Safety Connections between a GuardLogix Controller and POINT Guard I/O Modules on a DeviceNet Network Chapter 7
5. On the Module Definition dialog box, set these parameters for your
module.
6. Click the Connection tab.
7. Set the Configuration Assembly Instance to 864 for all POINT Guard
modules.
Cat. No. Product Type Product Code
1734-IB8S 35 15
1734-OB8S 35 16
1734-OBV2S 35 32
1734-IE4S 42 1
1734-IB8S Module 1734-IE4S Module
