138 Rockwell Automation Publication 1734-UM013N-EN-P - September 2017
Chapter 7 Configuring Safety Connections between a GuardLogix Controller and POINT Guard I/O Modules on a DeviceNet Network
8. Determine which assemblies you want to connect to and set the safety
input and output assemblies by using the following tables.
Table 5 - 1734-IB8S Input Assemblies
Safety Input Connection Input Assembly Safety
Input Number
Input Assembly Safety
Output Number
Size
Safety 516 (204 h) 199 (C7h) 1
Safety + Combined Status – Muting 788 (314 h) 199 (C7h) 2
Safety + Pt. Status 548 (224 h) 199 (C7h) 2
Safety + Pt. Status – Muting 820 (334 h) 199 (C7h) 3
Safety + Pt. Status – Muting – Test
Output
868 (364 h) 199 (C7h) 4
Table 6 - 1734-IB8S Output Assemblies
Safety Output Connection Output Assembly Safety
Input Number
Output Assembly Safety
Output Number
Size
Test 199 (C7h) 33 (21 h) 1
Table 7 - 1734-OB8S Input Assemblies
Safety Input Connection Input Assembly Safety
Input Number
Input Assembly Safety
Output Number
Size
Safety Output Status 580 (244 h) 199 (C7h) 1
Output Status + Monitor 1028 (404 h) 199 (C7h) 2
Safety Monitor + Combined Status +
Power
1044 (414 h) 199 (C7h) 2
Table 8 - 1734-OB8S Output Assemblies
Safety Output Connection Output Assembly Safety
Input Number
Output Assembly Safety
Output Number
Size
Safety 199 (C7h) 564 (234 h) 1
Table 9 - 1734-OBV2S Input Assemblies
Safety Input Connection Input Assembly Safety
Input Number
Input Assembly Safety
Output Number
Size
Safety Output Status 579 (243 h) 199 (C7h) 1
Output Status + Monitor 1027 (403 h) 199 (C7h) 1
Safety Monitor + Combined Status +
Power
1043 (413 h) 199 (C7h) 2
Table 10 - 1734-OBV2S Output Assemblies
Safety Output Connection Output Assembly Safety
Input Number
Output Assembly Safety
Output Number
Size
Safety 199 (C7h) 563 (233 h) 1
