Allen-Bradley 1734-OB8S User Manual

186 Rockwell Automation Publication 1734-UM013N-EN-P - September 2017
Appendix C Specifications
Figure 58 - Frequency Response of Voltage Input with Filter = 1 Hz
Figure 59 - Frequency Response of Voltage Input with Filter = 5 Hz
0.01 0.10 1.00 10.00 100.00 10000.001000.00
-30
-20
-10
0
-40
-70
8 0
-60
-50
-90
Frequency (Hz)
Frequency Response (dB)
ADC resolution = -72.2 dB
0.01 0.10 1.00 10.00 100.00 10000.001000.00
-30
-20
-10
0
-40
-70
8 0
-60
-50
-90
Frequency (Hz)
Frequency Response (dB)
ADC resolution = -72.2 dB

Allen-Bradley 1734-OB8S Specifications

General

Brand	Allen-Bradley
Model	1734-OB8S
Category	Control Unit
Language	English
